Given this situation: You have a GPS device that is connected to your computer (not handheld) via physical COM1. Now you want to use this data in two different applications, say: a Route Navigator and a GPS logger. You launch the Route Navigator, it’ll connect to the COM1 port and it’ll show you your position. Now, launch your GPS logger and try to connect on COM1. It’s not happening: that COM port is in use. You can connect to a COM port with only one application.
On a portable device, this is solved by installing a virtual COM port, which can be read by multiple applications simultaneously. Often, this is COM8 (so it is on my Windows Mobile 5 system). But what to do when you want this functionality on a normal pc?
XPort
Well, there is a very cool application that actually makes this possible. It’s called XPort. Just launch the application, hit “Find GPS”, select a virtual COM port in the right column and hit “Enable ports”. Now, you can connect with both applications to that selected virtual COM port. Or, you can select two virtual COM ports and have both applications connected on a different port.
There’s a little drawback. The application needs Administrative rights, so on your own computer at home it’ll work, but if you have to set this thing up on a terminal build in a truck and running Windows XP on which the GPS logger starts up silently and the Route Navigator launches in full screen, all automatically while a very limited user is logged on, XPort will be denied to launch the virtual COM ports since it should be run with administrative rights.
com0com
So we need an application that makes it possible to install the virtual COM ports as an administrator, then launch the mapping as a windows service.
I found com0com.
Using the application com0com, you can create virtual COM port pairs, each representing a virtual NULL Modem Cable. You can use the graphical interface, setupg or the commandline interface setupc. This last one can be used in scripts. I created three pairs, one for the Route Navigator, one for my software and one for later usage supposing that I might want to debug one day while the other apps are running. So my script looks like this:
setupc install 0 - PortName=COM14,EmuBR=yes
setupc change CNCA0 EmuBR=yes
setupc install 1 - PortName=COM15,EmuBR=yes
setupc change CNCA1 EmuBR=yes
setupc install 2 - PortName=COM16,EmuBR=yes
setupc change CNCA2 EmuBR=yes
This will create the following pairs:
CNCA0 <-> COM14
CNCA1 <-> COM15
CNCA2 <-> COM16
hub4com
Part of the project is hub4com that makes it possible to get the input from one COM port an route it to several others. The first example they give, is exactly that what I need.
You have a GPS device that connected to your computer via a phisical COM1 port and you’d like to handle its data by two GPS applications. You can do it this way:[..]
Following the rest of the example, while using COM6 as GPS COM port, CNCAx as virtual input, COM1x as virtual output, it showed me this on the commandline:
C:\com0com\>hub4com \\.\COM6 \\.\CNCA0 \\.\CNCA1 \\.\CNCA2
Open("\\.\COM6", baud=19200, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Open("\\.\CNCA0", baud=19200, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Open("\\.\CNCA1", baud=19200, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Open("\\.\CNCA2", baud=19200, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Route data COM6(0) --> CNCA0(1) CNCA1(2) CNCA2(2)
Route data CNCA0(1) --> COM6(0)
Route flow control COM6(0) --> CNCA0(1)
Route flow control CNCA0(1) --> COM6(0)
Started COM7(0)
Started CNCA0(1)
Started CNCA1(2)
When I now connect the GPS logger on COM5, I see a lot of trash appearing. The reason is that the baud rate doesn’t match. It’s very important to read from the COM port at the same rate as the device produces it’s data. The GPS receiver in my case has a speed of 9600 Bd, but as you can see in the console log, hub4com is reading it at 19200 Bd. Too fast, thus the trash.
Of course, hub4com provides a way to set the baud rate, option --baud=9600 is bringing it down and the output is now
C:\com0com>hub4com --baud=9600 \\.\COM6 \\.\CNCA0 \\.\CNCA1 \\.\CNCA2
Open("\\.\COM6", baud=9600, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Open("\\.\CNCA0", baud=9600, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Open("\\.\CNCA1", baud=9600, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Open("\\.\CNCA2", baud=9600, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Route data COM6(0) --> CNCA0(1) CNCA1(2) CNCA2(3)
Route data CNCA0(1) --> COM6(0)
Route flow control COM6(0) --> CNCA0(1)
Route flow control CNCA0(1) --> COM6(0)
Started COM6(0)
Started CNCA0(1)
Started CNCA1(2)
Started CNCA2(3)
Maybe it’s just me, but it took me a full day to understand what is happening now after reading and re-reading all information I could find. Launching the Route Navigator on COM14 will give you a GPS signal and launching the GPS logger on COM15 or COM16 will give you a signal as well. So far so good. Until you close the application on COM14. It doesn’t matter which one that is, Route Navigator or GPS logger, it all gives the same result. When the application on COM14 is closed, the signal is lost on COM14 and COM15. Although the configuration of all 3 ports are identically, the hub4com ReadMe states (adjusted to fit my example) that
It will send data received from COM6 port to CNCA0, CNCA1 and CNCA2 ports
and it will send data received from CNCA0 port to COM6 port.
As seen on the commandline:
Route data COM6(0) --> CNCA0(1) CNCA1(2) CNCA2(3)
Route data CNCA0(1) --> COM6(0)
Route flow control COM6(0) --> CNCA0(1)
Route flow control CNCA0(1) --> COM6(0)
The data is routed to all three COM ports, the “flow control” is applied from COM6 to CNCA0 and CNCA0 to COM6 (with CNCA0 the input for COM14). No flow control for the others is configured. So my only guess was to create a flow control to all others as well. One of the extended examples (got by issuing hub4com --help) stated this
hub4com --route=All:All \\.\CNCB0 \\.\CNCB1 \\.\CNCB2
- receive data from CNCB0 and send it to CNCB1 and CNCB2,
receive data from CNCB1 and send it to CNCB0 and CNCB2,
receive data from CNCB2 and send it to CNCB0 and CNCB1.
So that’s almost what I wanted to do. Assuming the syntax is consistent with, say, connect:
--connect=<lstr>:<lstl>
handle data sent to any port listed in <LstR>
as data received by all ports listed in <LstL>.
(where I would have switched R and L by the way) and where --route=All:All says that "ports can talk to each other", I added the parameter --route=0:All to route all data always from 0 to the others, so from COM6 to COM14, COM15 and COM16:
C:\com0com>hub4com --baud=9600 --route=0:All \\.\COM6 \\.\CNCA0 \\.\CNCA1 \\.\CNCA2
Open("\\.\COM6", baud=9600, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Open("\\.\CNCA0", baud=9600, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Open("\\.\CNCA1", baud=9600, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Open("\\.\CNCA2", baud=9600, data=8, parity=no, stop=1, octs=on, odsr=off, ox=off, ix=off, idsr=off, ito=0) - OK
Route data COM6(0) --> CNCA0(1) CNCA1(2) CNCA2(3)
No route for flow control
Started COM6(0)
Started CNCA0(1)
Started CNCA1(2)
Started CNCA2(3)
With this setup the data always flows from COM6 to the others no matter which port is read or left unread.
It took me about four days to find out how com0com and hub4com work, mainly because there’s not much information about it. There are quite a few examples, but none of them are explained in detail.
I sure hope the developers are still maintaining this application, since it really does what it has to and works like a charm. I hope the lack of updates since December 2009 is just because the application works perfectly
My final command is this:
hub4com
--baud=9600 --route=0:All \\.\COM11
--baud=9600 \\.\CNCA0
--baud=9600 \\.\CNCA1
--baud=9600 \\.\CNCA2
I added the --baud=9600 to all other Null cable entrances, but that’s more a leftover from my tests. I think it’s sufficient to add the parameter before the list of com ports.
Install as Windows Service
Once configured, the Virtual COM ports stay active until you remove them. However, you have to launch hub4com every time you have rebooted the computer. To solve that, I’ve used runassvc, which allows a silent install as well. Without parameters, the application launches a GUI in which you can enter the required values. With parameters, like opened through a bat file, it launches and enters the parameters you have defined. Then, when you use --quiet as parameter, the GUI doesn’t launch, but the service is installed and started. My command looks like this
RunAsSvc.exe
--install
--displayname "hub4com"
--description "Routes the GPS data from COM6 to virtual COM14, COM15 and COM16"
--exe "C:\com0com\hub4com.exe"
--params "--baud=9600 --route=0:All \\.\COM6 --baud=9600 \\.\CNCA0 --baud=9600 \\.\CNCA1 --baud=9600 \\.\CNCA2"
--workingdir "C:\com0com"
--quiet
Now, even when the computer is rebooted, as soon as it has started and before any user has logged on, the system is running so every application is able to read one GPS device even if another is already accessing it. It was tested successfully on a Windows XP and even on a Windows 7 machine, although on the last one you have to boot the machine in Test configuration (bcdedit -set TESTSIGNING ON) otherwise the com0com drivers won’t load.
Used applications
The applications I used to set up this environment, are
